Applications

• High lumens (e.g. 1000W HID Replacement)
• Direct HID retrofit
• Enclosed fixtures retrofit (eg. high mast)
• High temperature environment (eg. steel plants)
• High ceiling (eg. aircraft hangers)

General

• 50,772 Lumens @ 280W @ 80 CRI
• Compatible for all HID Ballast types  250-1000W
• Universal Voltage 120-480VAC
• Temperature
  • Upto T(Ambient) = 70ºC @ 200W
  • T(Ambient) = 40ºC enclosed fixture
• Low Glare, UGR<23
• 80 CRI Standard
• Five Year warranty

Certifications

• IP65
• ETL wet listed

Control Options

• 3 pin connector for off the shelf control modules
• Control not compatiable with ballast operation
• Power settable using NFC Phone Application

Mechanical

• Mogul Base
• Vertical Orientation
• 3.55 lb / 1.61 kg
• Ø 10.53" (268 mm) x 11.30" (287 mm)

Electrical

• VH: Hybrid: Ballast Compatible & 120-480 VAC
• <1% Flicker
• PF > 0.9, THD<20%
• Surge: 6 kV (L-N)

The Hybrid series is compatible with HID magnetic ballast between 250-1000W. Such ballast types include probe start, pulse start, CWA, or reactive. The table below shows compatible ballast that have been tested. Input to ballast may be up to 480V. Optical distribution and lumen output are constant regardless of Ballast type or wattage. Ballast operation is not compatible with dimming or controls.
