VALTO 700 PGZ EB Light Source

Project

Type

Part Number

Date

Summary

  • Only product UL certified for operation with Philips Electronic Ballast Master Color Elite Medium Wattage Ballast IZTMH210315RLFM
  • Five years or 50,000 hours warranty3
  • Open and vented fixture
  • 32,000 Lumen 210W
  • 25,000 Lumen 165W with optional dimming resistor
  • Power Consumption – 165W Light Source only with resistor to dim ballast power to output of 165W
  • Ambient air operation to 65°C/122°F
  • Built in Thermal Shut down (resettable)
  • PF>0.9 with electronic ballast

Mechanical

  • PGZ 18 socket
  • Vertical orientation only
  • Beautiful anodized solid aluminum body
  • 1.65 kg/3.6 lb
  • Fanless for high reliability and efficiency
  • Safety harness optional

Photometry

  • Compatible with uplight accessory
  • Compatible with Holophane Fixure Enduration 21PPE

Ballast Compatibility - Type A

EB Series is compatible with Electronic Ballast including Philips Electronic Ballast Master Color Elite Medium Wattage Ballast IZTMH210315RLFM

Certification



Order Information

Fixture Compatiability

Open or Vented

Max.Envir.
Temp.

65°C

Product
Code

03298

Part #

V2M-PGZ-200-8-40-E1-AN-B90-000-000

Watts

210

Lumens

32,000

CRI

>80

CCT

4,000K
  1.  Unless otherwise specified, all values are typical at 25°C with no optical accessory.
  2.  65°C for open or vented fixture, 45°C in total enclosed for Enclosed or IC Fixture.
  3.  See limited warranty for details.
  4.  Not intended for use in wet environments or environments containing airborne corrosive agents such as chemicals, solvents or cutting fluids.
  5.  Specifications subject to change without notice.

VER 201104
